Run two valves independently using one pair of field wires



About Us

Founded by licensed irrigators with over 20 years’ experience in system installation and repair, New Zone Irrigation is chartered with providing cost-effective solutions for irrigation professionals as well as Do-It-Yourselfers.  Our introductory product, New Zone, enables you to run two valves independently using only one pair of field wires.



We began research and development in 2018.  Within three months we had manufactured prototypes on hand to test the design and functionality.  Once this process was completed the product’s design was finalized and pre-release testing began.  Since 2018 New Zones have been successfully installed in the Dallas area with a zero percent failure rate. New Zone became commercially available in March 2020.

Rectangle 17.png

Each New Zone is hand-tested prior to packaging

$70.00

Orders over $250 ship FREE

Very good product and Very competitively priced.

- Don Garner, NXTGen Irrigation & Lawn Care

The evolution of New Zone from prototype to production.

To play, press and hold the enter key. To stop, release the enter key.

Each assembly is filled with an epoxy compound to protect the circuit boards from thermal extremes, chemicals, dust, salt, moisture and corrosion.

I've installed over twenty New Zones during the past two years at customer’s homes. Clear instructions are easy to follow making installation a breeze. New Zone saves me time and my customers the additional expense of locating a cut wire/bad splice or running a new wire to their controller. Very good product.

Zoe Vickers

Glen Cove Irrigation

Great product that works as advertised.  Easy to install as the instructions and diagrams are clear and straightforward.   Ordering is simple, the price is very competitive and we always keep multiple New Zones in our trucks.



Mauricio Soto

Water Cloud Irrigation

I have purchased and installed many New Zones and am completely satisfied with the product, customer service and timely delivery.  I would recommend New Zone without hesitation.



Cindy Lowe

American Sprinkler Repair

Group 7.png

Effective and Simple

New Zone enables you to run two valves independently using only one pair of field wires. It’s a cost-effective solution for reactivating a valve due to cut wires as well as adding a new valve to your system.

Group 6.png

Save Time & Money

Eliminates the need to trench and install new field wires from the new, or repaired valve, to the controller. Clear instructions and diagrams ensure timely installations and repairs.

Group 1.png

Design to Work Seamlessly

Valves run independently providing the flexibility to manage diverse watering requirements. Continue running separate watering schedules on multiple programs in both manual and automatic settings.

Orders over $250 ship FREE.



Installation

Valve Adapter

  1. Connect Yellow wire and White wire to a working valve’s solenoid wires

  2.  Connect Red wire and White wire to the solenoid wires of the non-working valve

  3. Connect Blue wire to the working valve’s field wire (from the controller) and White wire to field common wire

Controller Adapter

  1. Connect Yellow wire to the output terminal of the working valve

  2. Connect Red wire to the output terminal of the non-working valve

  3. Connect Blue wire to the field wire of working valve

Rectangle 19.png

Valve Adapter

  1. Connect Yellow wire and White wire to the existing valve’s solenoid wires

  2. Connect the Red wire and White wire to the solenoid wires of the new valve

  3. Connect the Blue wire to the existing valve’s field wire (from the controller) and White wire to field common wire

Controller Adapter

  1. Connect the Yellow wire to the output terminal of the existing valve

  2. Connect the Red wire to an unused output terminal

  3. Connect the Blue wire to the existing valve's field wire

image 1 (1).png


New Zone Product Guide
